Under Drive 5T Heavy Load (W5000DL)

LiDAR SLAM nabigation+5T heavy load liftking and transporting
Availability:
Quantity:

Basic Specification Model W5000DL
Self-weight 1500KG
Payload 5000KG
Positioning accuracy ±10mm
Lifting height 110mm
DimensionL*W*H 2470*1520*600mm
Navigation LiDAR SLAM Navigation
Drive mode Double wheel differential
Motion form Omni-directional
Traverse deviation ±1°
Turning angle deviation ±1°
Lifting time 5-8s
Rotation time 5-8s
Traveling speed(empty load) 0.8m/s
Traveling speed(full load) 0.6m/s
Battery Charging mode Auto+Manual charging
Drive voltage DC48V
Battery type Lithium iron phosphate
Battery cycle life 1500 times
Endurance 8h
Charging time 2.5h
Fast battery design Support
Safety Obstacle avoidance 360°LiDAR Obstacle avoidance+
Emergency switch Availableswitch at each side
Communication WIFI
Audible alarm Support
API interface Open
